EN IEC 61010-2-032:2021 Standard

wave
Save

  Keywords:

#circuits #sensor #protection #conductors #type

This standard can be totally or partially supervised by:
  •   EN IEC 61010-2-032:2021/A11:2021
  •   Directive

    Low voltage (LVD) Directive (2014/35/EU)

      Last Official Journal reference

    Wednesday 13th of December 2023

      Description:

    Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 2-032: Particular requirements for hand-held and hand-manipulated current sensors for electrical test and measurement

      Purpose

    This clause of Part 1 is applicable except as follows:1.1.1 Equipment included in scopeReplace the existing text with the following:This part of IEC 61010 specifies safety requirements for HAND-HELD and hand-manipulated current sensors described below.These current sensors are for measuring, detecting or injecting current, or indicating current waveforms on circuits without physically opening the current path of the circuit being measured.They can be stand-alone current sensors or accessories to other equipment or parts of combined equipment (see Figure 101). These include measurement circuits which are part of electrical test and measurement equipment, laboratory equipment, or process controlequipment. These current sensors and circuits need additional protective means between the current sensor, the circuit and an OPERATOR.NOTE 1 Combined equipment is equipment that is electrically connected to a current sensor by means of a permanent connection which can be detached only by the use of a TOOL.NOTE 2 Some current sensors are also known as current clamps, CLAMP MULTIMETERS and current probes.Current sensors are hand-manipulated before and/or after a test or measurement, but do notnecessarily need to be HAND-HELD during the test or measurement. Current sensors used as FIXED EQUIPMENT are not within the scope of this document.The following types of current sensors are covered:a) Type A: a current sensor designed to be applied to or removed from HAZARDOUS LIVE UNINSULATED CONDUCTORS. Type A current sensors have defined HAND-HELD or handmanipulated parts providing protection against electric shock from the conductor being measured, and also have protection against short -circuits between wires and betweenbusbars during clamping.b) Type B: a current sensor which has protection against short -circuits between wires or busbars during clamping but without defined HAND-HELD or hand-manipulated parts which provide protection against electric shock during clamping. Additional protective means arenecessary to avoid electric shock from HAZARDOUS LIVE conductors which cannot be deenergised during application or removal of the current sensor.EXAMPLE 1 Flexible current sensors.c) Type C: a current sensor without protection against short -circuits between wires or busbars during clamping. Type C current sensors are intended to be applied to or removed from HAZARDOUS LIVE UNINSULATED CONDUCTORS or from non-limited-energy circuit conductors only when they are de-energised.EXAMPLE 2 Split-core transducers.d) Type D: a current sensor designed to be applied to or removed from insulated conductors or from limited-energy circuit conductors.EXAMPLE 3 Current probes for oscilloscopes and earth leakage current detectors.All current sensors can also be used with insulated conductors. In this case, HAZARDS are limited to acceptable levels by the insulation of the conductors.Additional requirements for CLAMP MULTIMETERS are given in Annex EE.Figure 101 shows graphical representations of typical current sensors for illustration purposes.Current sensors can look different depending on the design.1.2.1 Aspects included in scopeAdd the following three new paragraphs at the end of the subclause:Requirements for protection against HAZARDS resulting from NORMAL USE and REASONABLYFORESEEABLE MISUSE of measuring circuits are given in Clause 101.Requirements for prevention of HAZARD from arc flash and short-circuits are given in Clause 102.Requirements for reliance on the displayed value of CLAMP MULTIMETERS are given in Clause EE.5 .

      Publication

    Tuesday 10th of May 2022

      Related Standards

    EN 61558-2-8:2010

    Low voltage (LVD) Directive (2014/35/EU)

    Safety of transformers, reactors, power supply units and combinations thereof - Part 2-8: Particular requirements and tests for t...

    EN 61204:1995

    Low voltage (LVD) Directive (2014/35/EU)

    Low-voltage power supply devices, d.c. output - Performance characteristics

    EN 61347-2-9:2013

    Low voltage (LVD) Directive (2014/35/EU)

    Lamp controlgear - Part 2-9: Particular requirements for electromagnetic controlgear for discharge lamps (excluding fluorescent la...

    EN 61347-2-3:2011/AC:2011

    Low voltage (LVD) Directive (2014/35/EU)

    Lamp control gear - Part 2-3: Particular requirements for a.c. and/or d.c. supplied electronic control gear for fluorescent lamps

    EN 61347-2-2:2012

    Low voltage (LVD) Directive (2014/35/EU)

    Lamp controlgear - Part 2-2: Particular requirements for d.c. or a.c. supplied electronic step-down convertors for filament lamps

    EN 61347-1:2015

    Low voltage (LVD) Directive (2014/35/EU)

    Lamp controlgear - Part 1: General and safety requirements
